Process Skids & Modules

01 / 07

A process skid, built as one package

Base, frame, decks and piping fabricated together in our works, so the package arrives complete and is set in a single lift.

Scroll to see how it is built · drag to turn it round

02 / 07

A base that stays true

Beams cut, drilled and welded so the base stays flat and square once dozens of small connections are welded onto it, and lifts from four lugs without racking the pipework.

How is it possible at Allmarc?

Kotec newRun10DX CNC beam drilling lineH-beams up to 1,000 x 500 mm

Used here for: A base that stays true

Heavy profiles that need precise holes, where plasma cannot do the job: the lower structure and panel borders of a ground flare, and every bolted PEB and multi-storey frame.

• H-beams up to 1,000 x 500 mm
• Drills 3 faces in one pass
• Channels, angles and box sections

All our machinery

Robotic H-beam cutting and bevelling cellBeams up to 1,000 x 500 mm

Used here for: A base that stays true

• Beams up to 1,000 x 500 mm
• 12 m long, 50 mm thick
• Hypertherm XPR 300

All our machinery

03 / 07

Square to the millimetre

The frame is fabricated square so that equipment nozzles meet the piping first time.

How is it possible at Allmarc?

SKDX1030 CNC end-face millingMills beam and column ends square for bolted splices

Used here for: Square to the millimetre

• Mills beam and column ends square for bolted splices

All our machinery

04 / 07

Small-bore piping, 6G welders

Many small pipes and fittings in a tight space. This is where skid work is won or lost: welders qualified to 6G, and fit-up checked before every weld.

How is it possible at Allmarc?

Manual MIG weldingQualified welders, including 6G

Used here for: Small-bore piping, 6G welders

• Qualified welders, including 6G

All our machinery

CNC pipe bendingCNC pipe and tube bending

Used here for: Small-bore piping, 6G welders

• CNC pipe and tube bending

All our machinery

05 / 07

Access

Grated upper deck, handrail and toe board, and a ladder.

How is it possible at Allmarc?

Grip-Strut walkway automation linePunching, embossing, edge bending, shearing

Used here for: Access

• Punching, embossing, edge bending, shearing
• Single-piece planks up to 8 m

All our machinery

06 / 07

Your equipment, our package

The vessel and pumps are yours. We build everything that carries, connects and reaches them.

07 / 07

Every part, apart

Base, frame, decks, piping and access.
