Blade Transport Fixtures

01 / 06

A blade has to arrive whole

A blade is long, light and easy to damage. The fixtures hold it by its root and near its tip, and nowhere else.

Scroll to see how it is built · drag to turn it round

02 / 06

Root frame

A braced frame of hollow sections, with A-frame struts down to the trailer deck, cut and welded in our bay.

How is it possible at Allmarc?

Robotic H-beam cutting and bevelling cellBeams up to 1,000 x 500 mm

Used here for: Root frame

• Beams up to 1,000 x 500 mm
• 12 m long, 50 mm thick
• Hypertherm XPR 300

All our machinery

Manual MIG weldingQualified welders, including 6G

Used here for: Root frame

• Qualified welders, including 6G

All our machinery

03 / 06

Root adapter

A ring plate drilled to the blade’s own bolt circle, so the root bolts straight on.

04 / 06

Tip cradle

A cradle with a curved, padded saddle and a clamp arm, so the shell is never point-loaded.

05 / 06

Lashed down

Chains and lashing points tie each fixture to the trailer.

06 / 06

Every part, apart

Root frame, adapter, tip cradle and pads.
